Air Tools - Air Nailers - Coil Nailers - Coil Nails |
|
|
|
Framing Nailers - Pallet Nailers Crating Nailers -
Sheathing Nailers - Siding Nailers - Roofing Nailers - Etc.. |
|
|
| |
|
|
|
Applications Include:
Framing, Sheathing, Strapping, Siding, Fencing, Trusses,
Exterior Decks, Bridging, Pallets & Crating, Wood to Masonry |
|
|
|
  |
|
|
|
N80CB Specifications:
- Driving Power (Inch Lbs.):880
- Nail Range: 1 1/2" - 3 1/4"
- Nail Capacity:300
- Operate Pressure (PSI):70-100
- Tool Height (In.):13
- Tool Length (In.):12-1/16
- Tool Width (In.):5-9/16
- Tool Weight (lbs.):8.4
|
  |
|
|
|
Click Model for your price now!
|
Coil
Framing Nails below fit:
|
Features & Benefits:
- Aluminum housing for site durability
- Coil magazine holds 300 nails for high
production
- Quick-open composite canister survives
falls
- Rubber grip for comfort
- Aggressive slip-free toe-nailing teeth
grip lumber
- Adjustable deflector conveniently directs
exhaust
|
|
Uses .099 - .148 Shank Diameter
15 Wire Collated Coil Nails. Available in: Coated, Galvanized, Stainless
Steel; Brown & White -15 Degree Wire &
Plastic Collated -1 1/2" - 2" - 2 1/2" - 3" - 3
1/4 |
|
|
| |
|
|
|
Applications Include:
Framing, Sheathing, Strapping, Siding, Fencing, Trusses,
Exterior Decks, Bridging, Pallets & Crating, Wood to Masonry |
|
|
|
 |
|
|
|
N89C Specifications:
- Driving Power (Inch Lbs.):1050
- Nail Range: 2" - 3 1/2"
- Nail Capacity:300
- Operate Pressure (PSI):70-120
- Tool Height (In.):14
- Tool Length (In.):12.25
- Tool Width (In.):5-9/16
- Tool Weight (lbs.):8.1
|
 |
|
|
|
Click Model for your price now!
|
Coil
Framing Nails below fit:
DuoFast:
CNW-75
Hitachi:
NV83A (1 1/2" - 3 1/4"); Hitachi
NV75AG (1-3/4”
- 3” x .099 -.131)
Makita:
AN901 (1 3/4" - 3 1/2")
Max:
890C
Paslode:
F275C/P275C (1 1/2" - 2 3/4"), F325C / P325C (1 1/2" - 3 1/4"), 5300C
(2" - 3")
Porter Cable:
Coil350
Senco:
SCN60 (2" - 2 1/2"), SCN65 (2" - 3 1/2")
|
Features & Benefits:
- Lightweight magnesium design for added durability
- Patented push button adjustable depth guide sets nail
to desired depths quickly and conveniently
- Coil magazine holds up to 300 nails for high
production applications
|
|
Uses .099 - .148 Shank Diameter
15 Wire Collated Coil Nails. Available in: Coated, Galvanized, Stainless
Steel; Brown & White -15 Degree Wire &
Plastic Collated 2" - 2 1/2" - 3" -3
1/4" - 3 1/2" |
|
|
| |
|
|
|
Applications Include: Wharfs,
Docks and Boardwalks, Hardwoods or Pressure Treated Lumber, Heavy-Duty Pallets
and Crating, Heavy-Duty Framing, Exterior Decks, Pole Barns, Barriers and
Foundations, Wood to Concrete or Masonry |
|
|
|
|
N400C-1 Specifications:
- Drive Power (Inch Lbs.):1450@100psi
- Nail Range: 2 1/2" - 4"
- Magazine Capacity:300
- Operate Pressure (PSI):70-100
- Thread Fitting Type: NPT
- Thread Size (In.):1/4
- Tool Height (In.): n/a
- Tool Length (In.):n/a
- Tool Weight (lbs.):10.7
- Tool Width (In.): n/a
|
 |
|
|
|
Click Model for your price now!
|
Coil
Framing Nails below fit:
DuoFast:
CNW-75
Hitachi:
NV83A (1 1/2" - 3 1/4"); Hitachi
NV75AG (1-3/4”
- 3” x .099 -.131)
Makita:
AN901 (1 3/4" - 3 1/2")
Max:
890C
Paslode:
F275C/P275C (1 1/2" - 2 3/4"), F325C / P325C (1 1/2" - 3 1/4"), 5300C
(2" - 3")
Porter Cable:
Coil350
Senco:
SCN60 (2" - 2 1/2"), SCN65 (2" - 3 1/2")
|
Features & Benefits:
- High-power engine drives
nails up to 4" length
- Coil magazine holds up to
300 nails
- Aluminum housing for job
site durability
- Quick-open composite
canister survives falls
|
|
Uses 15 Degree Wire Collated Coil Nail .099 -
.148 Shank Diameter. Available in: Coated, Galvanized |
|
15 Degree Wire & Plastic Collated - 2 1/2" - 3" - 3 1/4" - 3 1/2" - 4"
Coil Nails |
|
|
| |
|
|
|
Applications Include: Wharfs,
Docks and Boardwalks, Hardwoods or Pressure Treated Lumber, Heavy-Duty Pallets
and Crating, Heavy-Duty Framing, Exterior Decks, Pole Barns, Barriers and
Foundations, Wood to Concrete or Masonry |
|
|
|
 |
N100CPP Specifications:
- Drive Power (Inch Lbs.):1615
- Nail Range: 2 1/2" - 4"
- Magazine Capacity:225
- Operate Pressure (PSI):70-100
- Thread Fitting Type:NPT
- Thread Size (In.):3/8
- Tool Height (In.):17-3/4
- Tool Length (In.):15-3/16
- Tool Weight (lbs.):11.9
- Tool Width (In.):5-9/16
|
 |
|
|
|
Click Model for your price now!
|
Coil
Framing Nails below fit:
|
Features & Benefits:
- Power-packed engine drives nails up to 4"
- Secondary handle, rubber grip and integral
balancer mounting point in cap
|
|
Uses
15 Degree Wire Collated Coil Nail
.099 - .148 Shank Diameter. Available in: Coated, Galvanized, Stainless
Steel |
|
15
Degree Wire & Plastic Collated - 2 1/2" - 3" - 3 1/4" - 3 1/2" - 4"
Coil Nails |
|
|
| |
|
|
|
Applications Include: Wharfs,
Docks and Boardwalks, Hardwoods or Pressure Treated Lumber, Heavy-Duty Pallets
and Crating, Heavy-Duty Framing, Exterior Decks, Pole Barns, Barriers and
Foundations, Wood to Concrete or Masonry |
|
|
|
 |
N100C Specifications:
- Drive Power (Inch Lbs.):1350
- Nail Range: 2 1/2" - 4"
- Magazine Capacity:300
- Operate Pressure (PSI):70-100
- Thread Fitting Type:NPT
- Thread Size (In.):1/4
- Tool Height (In.):15-1/4
- Tool Length (In.):14-3/4
- Tool Weight (lbs.):10.7
- Tool Width (In.):5-9/16
|
|
|
|
|
Click Model for your price now!
-
N100C-1 Contact Trip
-
N100C-2 Sequential Trip
|
Coil
Framing Nails below fit:
|
Features & Benefits:
- High-power engine drives
nails up to 4" length
- Coil magazine holds up to
300 nails
- Aluminum housing for job
site durability
- Quick-open composite
canister survives falls
|
|
Uses 15° Wire Collated Coil Nail .099 -
.148 Shank Diameter. Available in: Coated, Galvanized |
|
15 Degree Wire & Plastic Collated - 2 1/2" - 3" - 3 1/4" - 3 1/2" - 4"
Coil Nails |
|
|
| |
|
|
|
Applications Include: Wharfs,
Docks and Boardwalks, Hardwoods or Pressure Treated Lumber, Heavy-Duty Pallets
and Crating, Heavy-Duty Framing, Exterior Decks, Pole Barns, Barriers and
Foundations, Wood to Concrete or Masonry |
|
|
|
 |
|
|
|
N130-2 Specifications:
-
Drive Power (Inch Lbs.):1615
- Nail Range (In.):3-1/2 to 5-1/8
- Magazine Capacity:225
- Operate Pressure (PSI):70-100
- Thread Fitting Type:NPT
- Thread Size (In.):3/8
- Tool Height (In.):17-3/4
- Tool Length (In.):15-3/16
- Tool Width (In.):5-9/16
- Tool Weight (lbs.):12.5
|
 |
|
|
|
Click Model for your price now!
|
Coil
Framing Nails below fit:
|
Features & Benefits:
- Power-packed engine drives nails up to
5-1/8"
- Aluminum housing for job site durability
- High-impact composite canister survives
falls
|
|
Uses 15
Degree Wire Collated Coil Nail .120 - .131 Shank Diameter.
Available in: Coated, Galvanized -
|
|
15 Degree Wire & Plastic Collated
- 3 1/2" - 4" - 4
1/2" - 4 3/4" - 5 1/8" |
|
|
| |
|
|
|
Applications Include:
Composition Roofing, Vapor Barrier Installation, Insulation Board (Adapter
Available) - DC6, Vinyl Siding (Adapter Available) - VSA2, Fiber Cement
Siding |
|
|
|
-
RN46B-1 Contact Trip
-
RN46B-2 Sequential Trip
|
RN46B Specifications:
- Driving Power:410 inch lbs
- Fastener Range:3/4" to 1-3/4"
- Magazine Capacity:120
- Operating Pressure:70-120 psi
- Power to Weight Ratio:83.6
- Thread Fitting Type:NPT
- Thread Size:1/4"
- Tool Height:10-5/8",269.88mm
- Tool Length:10-1/2",266.7mm
- Tool Width:4-5/8",117.48mm
- Tool Weight:4.8 lbs, 2.18 kilos
|
 |
Features & Benefits:
- Lightweight magnesium housing for jobsite durability
- Weighs only 4.8 lbs
- Dry-fire lockout; does not fire when empty
- Carbide inserts in tip for long life
- Over molded grip for comfortable use
- Quick-set adjustable depth control for consistent nail
drives
- Aggressive wear guards and skid resistant pads
- 410 inch pounds of driving energy for the hardest of
applications
- Patented single action side load canister
- Shingle guide with push button adjustments - no tools
needed
- Full round driver for more consistent drive quality
|
|
Uses:
CR Series 15
Degree Wire
Collated Coil Roofing Nail .120 Shank. Available in: Galvanized, Stainless
Steel |
|
|
| |
|
|
|
Important
- You and others working around you can be seriously
injured by fastener driving tools if you do not follow the instructions
provided on the tool and in the operations manual. Used properly,
these tools provide easy, safe and efficient methods for driving nails,
staples & rings.
Contact Trip - best
suited for high volume rapid fastening where exact placement of the
fastener is not important.
Sequential Trip -
best suited when rapid fastening is not needed or when exact
fastener placement is important. Evaluate your application to
determine the best trigger. See Safety Information for Trip
Operation! |
|
|
| |
|
|
